DSMSF-iLC-186233

Input Voltage(V)

AC 200V ~ 250V

Frequency

50Hz(+1% /–2%)

Power Consumption(W)

1W

Communication

Via the power supply

Switching Current

4A

Connection

0.5–1.5 mm²

Firmware update/ Parameter config.

Via power line

Surge voltage protection

4/1.2/50 KV in acc.

IP

IP20

Net Weight

0.1 Kg

Size(mm)

93 x 58 x 30 mm

Certification

CE
